INTRODUCING THE ALL-NEW

B-SERIES BATTERIES

IDEAL BATTERY SOLUTIONS FOR YOUR CYC EBIKE KIT

We designed the B-Series with one goal in mind: providing high-quality, durable, and sleek battery solutions. We know that every trip counts, so why not choose a battery that suitable for whatever you need. Check it out for yourself!

CE-Logo Certification.png
FCC-Logo Certification.png
ROHS-Logo Certification.png

*This product complies with UN38.3, IEC62133, RoHS, FCC, & CE standards

B-36/B-52/B-52L

VERSIONS AVAILABLE

FAST CHARGING

CAPABILITIES

36V & 52V

OPTIONS AVAILABLE

21700 CELLS

HIGH QUALITY SAMSUNG 21700 CELLS

B-Series-cells ice blue.png

ICE-BLUE BATTERY LEVEL INDICATORS

HIGH DISCHARGE BMS WITH SHORT-CIRCUIT PROTECTION

B-Series-cells image .png
Straps Step 1.png

SECURE & VERSATILE DUAL-MOUNTING SOLUTION

WEATHER & IMPACT RESISTANT

B-Series-cells impact.png

TECH SPECS

B-36

36V 10s2p

Samsung 50E 21700


50E: 10Ah (360Wh)


50E: 30A


2.2 kg

0.1 kg

199 x 81 x 104mm

Battery Voltage

Battery Cell Type


Battery Capacity


Max. Continious Current


Weight
(battery pack)

Weight (battery mount)

Dimensions (L x W x H)

B-52

B-52L

52V 14s2p

Samsung 40T 21700/
Samsung 50E 21700

40T: 8Ah (416Wh)
50E: 10Ah (520Wh)

40T: 70A
50E: 30A

2.9 kg

0.2 kg

259 x 81 x 104mm




52V 14s3p

Samsung 40T 21700 /
Samsung 50E 21700

40T: 12Ah (624Wh)
50E: 15Ah (780Wh)

40T: 70A
50E: 45A

4.3 kg

0.3 kg

364 x 81 x 104mm

BATTERY OPTIONS

SAMSUNG 40T 21700

B-52 Spec.png
  • Capacity: 416Wh

  • Charger type: 58.8V 4A XT90 2 hours until fully charged

  • BMS: 70A cont.

B-52

B-52L spec.png
  • Capacity: 624Wh

  • Charger type: 58.8V 4A XT90 3 hours until fully charged

  • BMS: 70A cont.

B-52L

SAMSUNG 50E 21700

B-36 Spec.png
  • Capacity: 360Wh

  • Charger type: 42V 3A XT90 3.5 hours until fully charged

  • BMS: 30A cont.

B-36

B-52 Spec.png
  • Capacity: 520Wh

  • Charger type: 58.8V 4A XT90 2.5 hours until fully charged

  • BMS: 30A cont.

B-52

B-52L spec.png
  • Capacity: 780Wh

  • Charger type: 58.8V 4A XT90 3-4 hours until fully charged

  • BMS: 45A cont.

B-52L
